TS315
2000-WATT 15-INCH 2-WAY POWERED LOUDSPEAKER
2000 W peak (1300 LF + 700 HF) 1000 W continuous RMS (650 LF + 350 HF)
15-inch (381 mm) LF driver, 3-inch (76 mm) high-temperature voice coil
1.4-inch (35 mm) neodymium magnet HF driver with precision wave guide
Pole-mountable, wedge monitor, bracket installation or flown application with integral M10 suspension points
Integrated 2-channel mixer with dual XLR 1/4-inch combo mic/line inputs, independent level controls, XLR Link output, Contour EQ switch and Ground-Lift switch
Custom-engineered high-efficiency class D amplifiers with passive cooling design – no fan means the speaker runs cleaner, quieter and has greater long-term reliability
Designed and tuned in the USA
DJ Speakers
HYBRID + HP15
HP15
* High Power Full Range
* Can be used as Point Source or Floor Monitor
* Loaded with Celto Acoustique Transducers
* Birch Plywood & UltraTex (USA) textured black finish
* M8 Flypoints – 7 Points
* Dual Angle Top-Hat 35mm (0° & 10°)
* Genuine Neutrik Speakon Connectors NL4MP
Specifications
RMS Power (AES Standard) : 600 Watt
Nominal Impedance: 8Ω
Average Sensitivity: 99dB/1W/1m
Max SPL (Calculated): 127dB RMS / 133dB Peak
Frequency Response (-6dB): 47Hz – 22000Hz
Nominal Directivity (-6dB): 80(H) x 50(V)
LF Transducer: Celto Acoustique, 15MB501-8
HF Transducer: Celto Acoustique, 1.5″ Exit, FCD738-8
Dimensions (HxWxD)mm : 730x445x425
Weight (Kg) : 25
HYBRID + PK218 BASSBIN
Dual 18″Sub-Bass Speaker
RMS Power | AES Standard | 1400W
Nominl Impendance | 4Ω
Average Sensitivity | 101dB / 1W / 1m
Maximum SPL, Calculated | 133dB RMS / 139dB Peak
Frequency Response: (-6dB) | 38Hz – 1800Hz
LF Component | 2 x Celto Acoustique, 18S700-8
Nominal Directivity | Omnidirectional
Cabinet Material | Braced BIrch Plywood
Cabinet Finish | UltraTex (USA) Textured Paint
Connectors | Neutrik Speakon NL4MP
Cabinet Size | 1200mm (h) x 510mm (w) x 600mm (d)
Hybrid Double Bassbin 18″ 800w LB218
Hybrid Double Bassbin 18" 800w Specifications: Dual 18″ Front loaded bass bin Cabinet Construction 93dB @ 1W/1M Cabinet Finish Polyurethane painted...
Hybrid PLB15 MKIII
15″ 340W Supa-wood, Polyurathane Finish
Frequency Response 50Hz-18Khz
Sensitivity 96dB @ 1W/1M
Power (AES) 340 W
LF Drivers 15″ 300 W (AES)
8Ω
3″ Voice coil
64 Oz magnet
HF Driver 40 W (AES)
8Ω
Titanium Diaphragm
1.75″ Voice Coil
22 Oz magne
Hybrid PLB215 MKII
LF Drivers 2 x 15″ 300 W (AES)
8Ω
3″ Voice coil
64 Oz magnet HF Driver 40 W (AES)
8Ω
Titanium Diaphragm
1.75″ Voice Coil
22 Oz magnet
Hybrid PM12
‘
Frequency Response 58Hz-18Khz
Sensitivity 94dB @ 1W/1M
Impedance 8 Ohm
Power (AES) 170 W
LF Drivers 12″ 150 W (AES)
8Ω
2″ Voice coil
40 Oz magnet
HF Driver 20 W (AES)
8Ω
Titanium Diaphragm
1.35″ Voice Coil
15 Oz magnet
HYBRID PM15
Frequency Response 52Hz-18Khz
Sensitivity 95dB @ 1W/1M
Impedance 8 Ohm
Power (AES) 220 W
LF Drivers 15″ 300 W (AES)
8Ω
2.5″ Voice coil
50 Oz magnet
HF Driver 20 W (AES)
8Ω
Titanium Diaphragm
1.35″ Voice Coil
15 Oz magnet
HYBRID+ HP218
* High Power Sub-Bass
* Loaded with Celto Acoustique Transducers
* Heavily Braced Birch Plywood & UltraTex (USA) textured black finish
* M12 Threaded Pole Adaptor
* Genuine Neutrik Speakon Connectors NL4MP
Specifications
RMS Power (AES Standard) : 2200 Watt
Nominal Impedance: 4Ω
Average Sensitivity: 101dB/1W/1m
Max SPL (Calculated): 134dB RMS / 140dB Peak
Frequency Response (-6dB): 35Hz – 1200Hz
Nominal Directivity : Omnidirectional
LF Transducer: Celto Acoustique, 18EX1100-8
Dimensions (HxWxD)mm : 1180x550x690
Weight (Kg) : 82
HYBRID+ HP218X
* High Power Sub-Bass
* Bandpass Horn Design
* Low Sub-Bass 28Hz Extension
* Loaded with Celto Acoustique Transducers
* Heavily Braced Birch Plywood & UltraTex (USA) textured black finish
* M12 Threaded Pole Adaptor
* Genuine Neutrik Speakon Connectors NL4MP
Specifications
RMS Power (AES Standard) : 3000 Watt
Nominal Impedance: 4Ω
Average Sensitivity: 104dB/1W/1m
Max SPL (Calculated): 140dB RMS / 146dB Peak
Frequency Response (-6dB): 28Hz – 300Hz
Nominal Directivity : Omnidirectional
LF Transducer: Celto Acoustique, 2x18EX1505-8
Dimensions (HxWxD)mm : 580x990x790
Weight (Kg) : 87
